Code: 588017

Electrolux Professional MACDACHOAO INFRARED TOP,4 ZONES,2-SIDE,800X800X250H (Code 588017, Alias 9CHG588017)

Product

Unit constructed according to DIN 18860_2 with 20 mm drop nose top. Internal frame for heavy duty sturdiness in 2 mm and 3 mm in 1.4301 (AISI 304). 2 mm top in 1.4301 (AISI 304). Flat surface construction, easily cleanable. THERMODUL connection system enables seamless worktop when units are connected and avoids soil penetrating. Glass ceramic cooking surface with 9 power levels and 4 independently controlled infrared heating zones. Overheat protection switches off the supply in case of overheating. Standby function saves energy and quickly recovers maximum power. Metal knobs with embedded hygienic silicon 'soft' grip enable easier handling and cleaning. Residual hot warning system enables safe operations. IPX5 water resistance certification. Configuration: Two-side operated top with backsplash. The base needs to be supplied by the factory. Please include appropriate base.

Buy Electrolux Professional MACDACHOAO INFRARED TOP,4 ZONES,2-SIDE,800X800X250H (Code 588017) online at a favorable price (prezzo, prix, precio, preço).

Specifications

Brand: Electrolux Professional
Model: MACDACHOAO
WxDxH mm: 800x800x250 mm
Weight: 38 Kg
Alias: 9CHG588017
Factory Model: MACDACHOAO
Customs_Class: 8419500090
Country of origin: Switzerland
Net Width: 800
Net Depth: 800
Net Height: 250
Electrical power: 16 Kw
Voltage: 400 V
Frequency: 50/60 Hz
Phases: 3N

Documents

Data Sheet: thermaline 80 - 4 Zone Infrared Top, 2 Side
Brochure: thermaline Modular 80&90
Range Overview: thermaline Modular 80
CAD Drawings: 588017
Spare Parts Catalogue: 588017
BIM/Revit: 588017

Shipping status

Upon Request

INFRARED TOP,4 ZONES,2-SIDE,800X800X250H (Code 588017)

Electrolux Professional MACDACHOAO (588017)

For many years, Electrolux Professional has supplied the market with kitchen sets of one of the highest quality.

Electrolux Professional MACDACHOAO (588017) is a unique electric stove with a solid surface that can be the perfect solution for your kitchen.

Main features:

Weight: 38 kg
Net Width: 800
Net depth: 800
Net height: 250
Electric power: 16KW
Voltage: 400V
Frequency: 50/60 Hz
Standby function to save energy and quickly restore maximum power
Two electronic sensors per zone to monitor the surface temperature and protect the burner from overheating
Metal handles with integrated hygienic silicone "soft" handle for easy handling and cleaning
9 power levels
Stainless steel inner frame for extra durability
All major components are easily accessible from the front
The THERMODUL connecting system creates a seamless working surface when units are connected, which prevents soil from penetrating vital components and makes it easy to remove units in case of replacement or maintenance
Virtually the entire surface of the ceramic plate can be used without dead spots
