Electrolux Professional MCGHACJOPI GAS TOP,4 BURNERS,ECO,2-S,1000X900X250H (Code 589084, Alias 9CHG589084)
Unit constructed according to DIN 18860_2 with 20 mm drop nose top. Internal frame for heavy duty sturdiness in 2 mm and 3 mm in 1.4301 (AISI 304). 2 mm top in 1.4301 (AISI 304). Flat surface construction, easily cleanable. THERMODUL connection system enables seamless worktop when units are connected and avoids soil penetrating. 4 gas burners with optimized combustion, flame failure device, thermocouple safety hand valve and protected pilot flame. Triple ring 'flower' flame burners with anti-clogging design. Manual gas valves allow precise flame intensity control. Large pan support in cast iron with long center fins for various pan sizes. ECOFLAM pan detection system to save energy and to reduce unnecessary heat radiation in the kitchen. Deep flat spillage tray with rounded corners and drain hole. Metal knobs with embedded hygienic silicon 'soft' grip enable easier handling and cleaning. IPX4 water resistant certification. Configuration: Two-side operated top with backsplash. The base needs to be supplied by the factory. Please include appropriate base.
Buy Electrolux Professional MCGHACJOPI GAS TOP,4 BURNERS,ECO,2-S,1000X900X250H (Code 589084) online at a favorable price (prezzo, prix, precio, preço).
- Brand: Electrolux Professional
- Model: MCGHACJOPI
- WxDxH mm: 1000x900x250 mm
- Weight: 82 Kg
- Alias: 9CHG589084
- Factory Model: MCGHACJOPI
- Customs_Class: 8419500090
- Country of origin: Switzerland
- Net Width: 1000
- Net Depth: 900
- Net Height: 250
- Gas power: 40 Kw
- Data Sheet: thermaline 90 - 4-Burner Gas Top with Ecoflam, 2 Sides
- Brochure: thermaline Book
- Range Overview: thermaline Modular 90
- CAD Drawings: 589084
- Spare Parts Catalogue: 589084
- BIM/Revit: 589084
Upon Request
Electrolux Professional MCGHACJOPI (589084)
Thermal equipment is designed for heat treatment of food products: pasteurization, sterilization, cooking, frying. An important element of this line is a gas top like Electrolux Professional MCGHACJOPI (589084).
You will learn to enjoy not only the result but also the process because working with this gas top is convenient, fast, and effective.
Main Features
- Gas top with 4 burners, and control panel on 2 sides with backsplash;
- Produced according to DIN 18860_2 with a 20 mm offset nose;
- Convenient front access to all key components;
- Metal regulators with silicone inserts;
- The THERMODUL connection system for a seamless work surface;
- Each burner is equipped with a thermocouple and a protected pilot burner;
- The top panel is made from steel AISI 304 (1.4301) 2 mm thick.
- The Ecoflam device allows you to reduce gas consumption and heat emission;
- A cast-iron divider with elongated legs-holders enables you to use crockery of any size;
- Sealing index - IPX5.
Electrolux Professional MCGHACJOPI Price
To purchase Electrolux Professional MCGHACJOPI (589084) at a favorable price, navigate to the MARAN Projekt GmbH online store.
It is the official distributor of Electrolux Professional techniques for more than 20 years. Relatively low cost of production provides high demand.
